CARGO LEGS
The tapered cargo legs welcome stuff sacks and water bottles up to 8" long to strap vertically with the support of the included dropout ledge spacer.
Compatability:
The V3 Legs were designed to be as adjustable as possible while maintaining maximum load rating. The mid fork legs should fit most forks with standard lowrider mid fork eyelets (165mm from dropout). A compatible fork will have eyelets that fall within both of the following ranges:
Fork Crown to Eyelet – 185mm-250mm (7 3/8″ – 9 7/8″)
Dropout to Eyelet – 130mm-195mm (5 1/8″ – 7 5/8″)
Numbers are based on a straight blade fork with 400mm axle-crown measurement, 50mm rake, on a 72degree headtube while clearing a 2.2″ tire. Different forks and curve profiles may skew these numbers.
